74ALVC164245.pdf? 5V Tolerant Inputs/Outputs for Interfacing with5V Logic
3V VCCA: 1.5V to 3.6V
5V VCCB: 1.5V to 5.5V
? CMOS Low Power Consumption
? Direct Interface with TTL Levels
? Control Inputs Voltage Range from 2.7V to 5.5V
? Inputs Accept Voltages up to 5.5V
? High-Impedance Outputs when VCCA or VCCB = 0V
? -40℃ to +125℃ Operating Temperature Range
? Available in a Green TSSOP-48 Package
? 5 V tolerant inputs/outputs for interfacing with 5 V logic
? Wide supply voltage range:
3 V port (VCC(A)): 1.5 V to 3.6 V
5 V port (VCC(B)): 1.5 V to 5.5 V
? CMOS low power consumption
? Direct interface with TTL levels
? Control inputs voltage range from 2.7 V to 5.5 V
? Inputs accept voltages up to 5.5 V
? High-impedance outputs when VCC(A) or VCC(B) = 0 V
? Complies with JEDEC standard JESD8-B/JESD36
? ESD protection:
HBM JESD22-A114F exceeds 2000 V
MM JESD22-A115-A exceeds 200 V
? Specified from -40℃ to +85℃ and -40 ℃ to +125℃
