74AVC16T245.pdf? Control Inputs VIH/VIL Levels Are
Referenced to VCCA Voltage
? VCC Isolation Feature – If Either
VCC Input Is at GND, Both Ports Are
in the High-Impedance State
? Overvoltage-Tolerant Inputs and
Outputs Allow Mixed-Voltage-Mode
Data Communications
? Fully Configurable Dual-Rail
Design Allows Each Port to Operate
Over the Full 1.2 V to 3.6 V Power-Supply Range
? Ioff Supports Partial-Power-Down Mode Operation
? I/Os Are 4.6 V Tolerant
? Maximum Data Rates
380 Mbps (1.8 V to 3.3 V Level-Shifting)
200 Mbps (<1.8 V to 3.3 V Level-Shifting)
200 Mbps (Level-Shifting to 2.5 V or 1.8 V)
150 Mbps (Level-Shifting to 1.5 V)
100 Mbps (Level-Shifting to 1.2 V)
? Latch-Up Performance Exceeds 100 mA Per JESD 78, Class
? ESD Protection Exceeds JESD 22
8000-V Human-Body Model (A114-A)
200-V Machine Model (A115-A)
1000-V Charged-Device Model (C101)
