74AVC4T245.pdf? VCCA Supply Voltage Range: 0.8V to 3.6V
? VCCB Supply Voltage Range: 0.8V to 3.6V
? Inputs Accept Voltages up to 3.6V
? +12mA/-12mA Output Current
? Data Rates:
380Mbps (≥ 1.8V to 3.3V Translation)
200Mbps (≥ 1.1V to 3.3V Translation)
200Mbps (≥ 1.1V to 2.5V Translation)
200Mbps (≥ 1.1V to 1.8V Translation)
150Mbps (≥ 1.1V to 1.5V Translation)
100Mbps (≥ 1.1V to 1.2V Translation)
? Outputs in High-Impedance State when VCCA or VCCB = 0V
? -40℃ to +125℃ Operating Temperature Range
? Available in a Green TSSOP-16 Package
? Control Inputs VIH/VIL Levels Are
Referenced to VCCA Voltage
? Fully Configurable Dual-Rail Design
Allows Each Port to Operate Over the
Full 1.2-V to 3.6-V Power-Supply Range
? I/Os Are 4.6-V Tolerant
? Ioff Supports Partial Power-Down-Mode Operation
? Maximum Data Rates
380 Mbps (1.8-V to 3.3-V Translation)
200 Mbps (< 1.8-V to 3.3-V Translation)
200 Mbps (Translate to 2.5 V or 1.8 V)
150 Mbps (Translate to 1.5 V)
100 Mbps (Translate to 1.2 V)
? Latch-Up Performance Exceeds 100
mA Per JESD 78, Class II
? ESD Protection Exceeds JESD 22
8000-V Human-Body Model (A114-A)
150-V Machine Model (A115-A)
1000-V Charged-Device Model (C101)
