74LVTN16244.pdf? 16-Bit Bus Interface
? 3-State Buffers
? Output Capability: +64mA/-32mA
? TTL Input and Output Switching Levels
? Input and Output Interface Capability to
Systems at 5V Supply
? 74LVTH16244: Bus Hold on Data Inputs Eliminates
the Need for External Pull-Up/Pull-Down Resistors
? Live Insertion and Extraction Permitted
? Power-Up 3-State
? No Bus Current Loading When Output is Tied to
5V Bus
? -40℃ to +125℃ Operating Temperature Range
? Available in a Green TSSOP-48 Package
?16-bit bus interface
? 3-state buffers
? Output capability: +64 mA and -32 mA
? TTL input and output switching levels
? Input and output interface capability to systems at 5 V supply
? Power-up 3-state
? Live insertion and extraction permitted
? No bus current loading when output is tied to 5 V bus
? Latch-up protection
? JESD78B Class II exceeds 500 mA
? ESD protection:
HBM JESD22-A114F exceeds 2000 V
MM JESD22-A115-A exceeds 200 V
