SCT2452C.pdf? Wide Input Range: 4.5V-42V
? Up to 5A Continuous Output Current
? 0.8V ±1% Feedback Reference Voltage
? Integrated 80mΩ High-Side MOSFET
? Low Quiescent Current: 100uA
? Pulse Skipping Mode (PSM) in light load
? 130ns Minimum On-time
? Programmable Soft-start Time
? Adjustable Frequency 100KHz to 2.2MHz
? External Clock Synchronization
? Precision Enable Threshold for Programmable
Input Voltage Under-Voltage Lock Out Protection
(UVLO) Threshold and Hysteresis
? Low Dropout Mode Operation
? Derivable Inverting Voltage Regulator
? Over-voltage and Over-Temperature Protection
? Available in an ESOP-8 Package
? Wide Operating Input Voltage Range : 4.5V to 36V
? Adjustable Output Voltage Range : 0.8V to 15V
? 0.6A Output Current
? 0.35Ω Internal Power MOSFET Switch
? High Efficiency up to 95%
? 1.2MHz Fixed Switching Frequency (Duty <90%)
? Support duty up to 95%
? Stable with Low ESR Output Ceramic Capacitors
? Thermal Shutdown
? Cycle-By-Cycle Over-Current Protection
