SGM2212-3.3XKC3G.pdf? Input Voltage Range: 2.7V to 20V
? Output Current: 800mA
? Fixed Output Voltages:1.8V, 2.5V, 2.8V, 3.3V, 5V
? Adjustable Output Voltage Range: 1.25V to 15V
? Output Voltage Accuracy: ±1% at +25℃
? Line Regulation: 0.012% (MAX)
? Load Regulation: 0.4% (MAX)
? Stable with Small Case Size Ceramic Capacitors
? Output Current Limit
? Thermal Shutdown Protection
? -40℃ to +125℃ Operating Temperature Range
? Available in Green TO-252-2, TO-263-3,
SOT-223-3 and TDFN-3×3-8L Packages
? 1.2V Maximum Dropout at Full Load Current
? 2% Tolerance Over Temperature,
Line and Load Variations
? Fast Transient Response
? Output Current Limiting
? Built-in Thermal Shutdown
? Good Noise Rejection
? Suitable for use with MLCC Capacitors
? Qualified to AEC-Q100 Grade 2
(see ‘Ordering Information’)
? PPAP capable (Note 4)
? -40 to +125°C Junction Temperature Range
? Available in TO252 and SOT223 with
“Green” Molding Compound(No Br, Sb)
Lead-Free Finish; RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free.
“Green” Device (Note 3)
