SKY85310-11: 2.4 GHz, 256 QAM WLAN/Bluetooth? Front-End Module,SGM22310A Replace SKY85310.
SGM22310A.pdf優(yōu)勢(shì)替代
FEATURES
? Integrated high-performance 2.4 GHz PA, harmonic
filter, LNA with bypass, and T/R switch
? Fully-matched input and output
? LNA with integrated bypass mode
? High performance SP3T switch to support Bluetooth
/WiFi functions
? Integrated positive slope power detector
? Transmit gain: 30 dB
? Receive gain: 12 dB
? Small QFN (16-pin, 3 x 3 mm) package
(MSL1, 260 °C per JEDEC J-STD-020)
PIN CONFIGUTION
