SGM2238Q.pdf? AEC-Q100 Qualified for Automotive Applications
Device Temperature Grade 1
TA = -40℃ to +125℃
? Operating Input Voltage Range: 3V to 40V
? Enable Pin Accept Voltages Higher than the
Supply Voltage and up to 40V
? Fixed Output from 1.8V to 12V
? Adjustable Output from 1.25V to 24V
? 300mA Output Current
? Low Quiescent Current: 3.3μA (TYP)
? Low Dropout Voltage:
410mV (TYP) at 300mA, VOUT = 5V
? Current Limiting and Thermal Protection
? Support Power-Good Indicator Function
? With Output Automatic Discharge
? Stable with Small Case Size Ceramic Capacitors
? -40℃ to +125℃ Operating Temperature Range
? Available in a Green SOIC-8 (Exposed Pad) Package
? 3V to 40V Input Range
? 10μA Quiescent Supply Current
? Stable with Low-value Output Ceramic Capacitor (> 0.47μF)
? 300mA Specified Current
? Fixed 5V, 3.3V, and Adjustable Output (1.2 V to 15 V) Versions
? Output ±2% Accuracy Over Temperature
? Specified Current Limit
? Power Good
? Programmable Power Good Delay
? Thermal Shutdown and Short-Circuit Protection
? -40°C to +150°C Specified Junction Temperature Range
? Available in a SOIC-8 EP Packages
? Available in AEC-Q100 Grade 1
