SGM2537.pdf? Input Voltage: 2.7V to 18V, Surge up to 20V
? Low On-Resistance: 35mΩ (TYP)
? Output Clamp Response Time: 5μs (TYP)
? Programmable Current Limit: 0.5A to 4A
? ±7.5% Current Limit Accuracy
? Load Current Monitor Output
? Programmable Soft-Start Time (SS)
? Over-Temperature Protection (OTP)
? Fault Flag (nFAULT Pin)
? Available in a Green TDFN-2×2-8AL Package
? Wide Input Voltage Range: 2.7 V to 18 V
– 20-V Absolute Maximum
– 3 V to 18 V for TPS2595x5 version
? Low On-Resistance: RON = 34 mΩ (typical)
? Overvoltage Protection Clamp (3.8-, 5.7-, and
13.7-V options)
? Adjustable Undervoltage Lockout (UVLO)
? Adjustable Current Limit with Monitor Output (ILM)
– Current Range: 0.5 A to 4 A
– Current Accuracy: ±10% (≥2 A)
? Fast Short Circuit Protection
? Adjustable Output Slew Rate Control (dVdt)
? Over Temperature Protection (OTP)
? Fault Indication Pin (FLT)
? UL 2367 Recognition (Pending)
? Safe During Single Point Failure Test (UL60950)
