SGM61410.pdf? Wide 5V to 42V Operating Input Voltage Range
? 0.8V Internal Reference
? Low Quiescent Current: 14μA (TYP)
? Shutdown Current: 0.6μA (TYP)
? 1.2MHz Switching Frequency
? Internal Compensation and Soft-Start
? Simple Design and Minimal External Components
? Up to 95% Efficiency at 12V/400mA
? 0.8V to 20V Adjustable Output Voltage
? Current Limit and Short-Circuit Protection
? Output Over-Voltage Protection and Thermal
Shutdown
? Power-Save Mode and PWM Mode Operation
? Monotonic Startup with Pre-biased Output
? 90% Maximum Duty Cycle
? Available in a Green SOT-23-6 Package
? -40℃ to +125℃ Operating Temperature Range
? Wide Input Voltage Range: 3.2V to 34V
? Micropower Operation: IQ = 12μA
? 5V at 250mA from 6.5V to 34V Input (LT1934)
? 5V at 60mA from 6.5V to 34V Input (LT1934-1)
? 3.3V at 250mA from 4.5V to 34V Input (LT1934)
? 3.3V at 60mA from 4.5V to 34V Input (LT1934-1)
? Low Shutdown Current: <1μA
? Low VCESAT Switch: 200mV at 300mA
? Low Profi le (1mm) SOT-23 (ThinSOT?)
and
(2mm × 3mm × 0.8mm) 6-Pin DFN Package
