SGM660.pdf? 2.8V to 5.5V Input Voltage Range
? Adjustable Output Voltage:
-0.8V to -5.2V, 0.1V/Step
? Programmable Switching Current Limit:
810mA (Default)/620mA/435mA
? Programmable Switching Frequency:
1.8MHz/1.6MHz (Default)/1.4MHz
? No External Compensation
? Internal Soft-Start Function
? Shutdown Current: 1μA (MAX)
? Available in a Green WLCSP-0.9×1.3-6B Package
? Wiper Position Stored in Nonvolatile Memory and Recalled Upon Power-Up
? 16-Pin, 5mm x 5mm x 0.8mm TQFN Package
? 35ppm/°C End-to-End Resistance Temperature Coefficient
? 5ppm/°C Ratiometric Temperature Coefficient
? 10k? and 50k? End-to-End Resistor Values
? 3-Wire SPI-Compatible Serial Interface
? Reliability (TA = +85°C)
50,000 Wiper Store Cycles
50 Years Wiper Data Retention
? 1.5μA (max) Standby Current
? Single +2.7V to +5.25V Supply Operation
? Dual ±2.5V Supply Operation
