0.4 to 6.0 GHz DPDT Low Insertion Loss / High-Isolation Switch，SGM72022 Replace SKY13699
SGM72022.pdf優勢替代
FEATURES
? Very low insertion loss: 0.3 dB @ 1 GHz,
1 dB @ 5.9 GHz
? High isolation: 32 dB @ 3.8 GHz
? Single-control voltage input
? Broadband frequency range: 0.4 to 6.0 GHz
? No DC blocking capacitors required
? Positive-control voltage range: 1.35 to 2.8 V
? GSM power handling
? Small MCM (10-pin, 1.55 × 1.15 × 0.59 mm
[typical]) package (MSL3, 260°C per JEDEC J-STD-020)
PIN CONFIGUTION
