SGM803B.pdf? Superior Upgrade for MAX803/MAX809/MAX810 and ADM803/ADM809/ADM810
? High Accuracy Fixed Detection Options: 3V, 3.3V and 5V
? Low Supply Current: 300nA (TYP)
? 150ms (MIN) Power-on Reset Pulse Width
? Reset Output Options:
Open-Drain nRESET Output (SGM803B)
Push-Pull nRESET Output (SGM809B)
Push-Pull RESET Output (SGM810B)
? Reset Valid Down to VCC = 1V
? Fully Specified over Temperature
? VCC Transient Immunity
? -40℃ to +125℃ Operating Temperature Range
? Available in Green SOT-23-3 and SOT-23 Packages
? Internally Fixed Threshold 1.2V to 5V in 0.1V Step
? High Accuracy ±1.5%
? Low Supply Current 3μA
? No External Components Required
? Quick Reset within 20μs
? Built-In Recovery Delay Include 0ms, 55ms, 220ms,
450ms Options
? Low Functional Supply Voltage 0.9V
? N-Channel Open-Drain Output
? Small SC-82, SC-70-3, SOT-23-3, SOT-23-5, SOT-89
Packages
? RoHS Compliant and 100% Lead (Pb)-Free
