SGM8270-4XTS14G.pdf? Wide Input Common Mode and
DifferentialVoltage Ranges
? Low Input Bias and Offset Current
? Output Short-Circuit Protection
? Rail-to-Rail Input and Output
? High Input Impedance
? Low Offset Voltage: 1.2mV (MAX)
? Low Noise: 15nV/ Hz at 1kHz
? Gain-Bandwidth Product: 2.2MHz
? High Slew Rate: 8V/μs
? -40℃ to +125℃ Operating
Temperature Range
? Available in Green SOIC-14
and TSSOP-14 Packages
? Rail-to-Rail Output
? Wide Bandwidth: 3 MHz
? High Slew Rate: 2.4 V/μs
? Supply Voltage Range: 2.7 V to 16 V
? Supply Current: 550 μA/Channel
? Input Noise Voltage: 39 nV/√Hz
? Input Bias Current: 1 pA
? Specified Temperature Range:
– Commercial Grade: 0°C to 70°C
– Industrial Grade: ?40°C to 125°C
? Ultrasmall Packaging:
– 5-Pin SOT-23 (TLV271)
– 8-Pin MSOP (TLV272)
? Ideal Upgrade for TLC72x Family
