SGM8742YMS8G.pdf? Fast, 45ns Propagation Delay (10mV Overdrive)
? Low Power Consumption:
305μA (TYP) at VS = 3V
? Wide Supply Voltage Range: 2.7V to 5.5V
? Optimized for 3V and 5V Applications
? Rail-to-Rail Input Voltage Range
? Low Offset Voltage: 0.9mV (TYP)
? Internal Hysteresis for Clean Switching
? Output Swing to within 200mV from Rails with
4mA Output Current
? CMOS/TTL-Compatible Outputs
? -40℃ to +85℃ Operating Temperature Range
? Available in Green SOIC-8 and MSOP-8 Packages
? 1.65 V to 5.5 V supply range
? Precision input offset voltage 300 μV
? Power-on Reset (POR) for known start-up
? Rail-to-Rail input with fault-tolerance
? 100 ns typical propagation delay
? Low quiescent current 16 μA per channel
? Low input bias current 5 pA
? Open-drain output option (TLV902x)
? Push-pull output option (TLV903x)
? Full -40°C to +125°C temperature range
? 2 kV ESD protection
