LC1208.pdf
No.10566
? Low Power Consumption:1.0uA（Typ.）
? Maximum Output Current:200mA
? Small Dropout Voltage
210mV@100mA (Vout=2.8V)
430mV@200mA (Vout=2.8V)
? Input Voltage Range:1.5V~6V
? Output Voltage Range:1.1V~5.5V
? Highly Accurate:±2%(±1% customized）
? Output Current Limit
LC1208 series is a group of positive voltage output, low power consumption, low dropout voltage, three terminal regulator. It can provide 200mA output current when input / output voltage differential drops to 430mV（Vout=2.8V）, The very low power consumption of LC1208（Iq=1.0uA）can greatly improve natural life of batteries. LC1208 can provide output value in the range of 1.1V~5.5V in 0.1V steps. It also can customized on command.
LC1208 includes high accuracy voltage reference, error amplifier, current limit circuit and output driver module. LC1208 has well load transient response and good temperature characteristic, And it uses trimming technique to guarantee output voltage accuracy within±2%.
