SGM48000/1/2.pdf
No.11044
● Improved Response Times
● Matched Rise and Fall Times
● Reduced Clock Skew between Dual Channels
● Low Output Impedance
● Output is at LOW under UVLO Protection
● High Noise Immunity
● Improved Clocking Rate
● Low Supply Current
● Wide Operating Voltage Range
● -40℃ to +125℃ Operating Temperature Range
● Available in Green SOIC-8 and TDFN-2×2-8L Packages
The SGM48000/1/2 ICs are matched dual-drivers. Unique circuit design provides very high speed drivers capable of delivering peak currents of 2A into highly capacitive loads. Improved speed and drive capability are enhanced by matched rise and fall delay times. These matched delays maintain the integrity of input-to-output pulse-widths to reduce timing errors and clock skew problems. Dynamic switching losses are minimized with non-overlapped drive techniques.
The SGM48000/1/2 are available in Green SOIC-8 and TDFN-2×2-8L packages. They operate over an ambient temperature range of -40℃ to +125℃.
