SGM8250-1.pdf
No.11324
? Low Offset Voltage: 50μV (MAX)
? Low 0.1Hz to 10Hz Noise: 0.85μVP-P
? Quiescent Current: 50μA/Amplifier (TYP)
? Single or Dual Supply Operation
? Supply Voltage Range: 3V to 24V
? Rail-to-Rail Input and Output
? -40℃ to +125℃ Operating Temperature Range
The single SGM8250-1 and dual SGM8250-2 CMOS operational amplifiers provide very low offset voltage and zero-drift over time and temperature.
The miniature, high precision, low quiescent current amplifiers offer high-impedance inputs that have a wide input common mode range of 100mV beyond the rails and rail-to-rail output that swings within 65mV of the rails. Single or dual supplies as low as 3V (±1.5V) and up to 24V (±12V) may be used. They are optimized for wide power supply range operation.
