SGM8954-2.pdf
No.11311
● Quiescent Current: 9μA/Amplifier (TYP)
● Low Offset Voltage: 8μV (TYP), 35μV (MAX)
● Low 0.1Hz to 10Hz Noise: 1μVP-P
● Gain-Bandwidth Product: 110kHz
● Unity-Gain Stable
● Integrated RFI Filter
● Single or Dual Supply Operation
● Supply Voltage Range: 1.8V to 5.5V
● Rail-to-Rail Input and Output
● -40℃ to +125℃ Operating Temperature Range
The single SGM8954-1 and dual SGM8954-2 CMOS operational amplifiers provide very low offset voltage and zero-drift over time and temperature.
The miniature, high precision, low quiescent current amplifiers offer high-impedance inputs that have a wide input common mode range of 100mV beyond the rails and rail-to-rail output that swings within 5.5mV of the rails. Single or dual supplies as low as 1.8V (±0.9V) and up to 5.5V (±2.75V) may be used. They are optimized for low voltage, single or dual supply operation.
The SGM8954-1/2 offer excellent CMRR without the crossover associated with traditional complementary input stages. This design results in superior performance for driving analog-to-digital converters (ADCs) without degradation of differential linearity.
