SGM8965A-1.pdf
No.11329
● Gain Bandwidth: 50MHz
● High CMRR: 94dB (TYP)
● Rail-to-Rail Input and Output
● Low Noise: 5.5nV/Hz at 100kHz
● Slew Rate: 30V/μs
● High Precision:
Low Offset: 50μV (TYP), 280μV (MAX)
Low Input Bias Current: 1pA (TYP)
● Unity-Gain Stable
● 2.2V to 5.5V Operation Voltage Range
● -40℃ to +125℃ Operating Temperature Range
The SGM8965A-1/2 are zero-crossover, rail-to-rail input and output, high-performance, CMOS operational amplifiers which are optimized for low voltage, single-supply applications. Rail-to-rail input and output, low noise and high speed operation make these devices ideal for driving sampling analog-to-digital converters (ADCs). Applications include audio, signal conditioning and sensor amplification. The SGM8965A-1/2 operational amplifiers are also well-suited for cell phone power amplifier control loops.
Special features include no input stage crossover distortion, high input impedance, and rail-to-rail input and output swing. The input common mode voltage range includes both the negative and positive supplies. The output voltage swing is within 6mV (TYP) of the rails.
